Dry Nitrogen Evaporator YKDC-200

1、Product Introduction

The nitrogen evaporator utilizes microprocessor control with PID fuzzy logic technology and high-purity aluminum as the heat-conducting medium, replacing traditional water baths. It offers user-friendly operation, wide temperature range, and high precision. By directing a rapid, continuous, and controllable flow of nitrogen/air onto heated sample surfaces, it enables high-speed concentration of multiple samples based on solvent evaporation rates and boiling points.

2、Product characteristic

1. Independent Gas Needles: Eliminates cross-contamination.
2. Individual Flow Control: Adjustable flow rate per needle.
3. Flexible Configuration: Channels work jointly or independently.
4. Intuitive Adjustment: Flow valves align vertically with module holes for easy operation.
5. Precise Temperature Control: Wide range with calibration function.
6. Safety Lift Mechanism: Features a locking bolt for durable use.

3、Technical Parameters
1. Model GDC-200
2. Temp. Range RT+5°C–160°C
3. Temp. Accuracy ±0.5°C (@40°C) / ±1°C (@120°C)4. Temp. Uniformity ±0.5°C
5. Heating Time (25°C→160°C) ≤15 min
6. Gas Pressure 0.1 MPa
7. Timer 1 min–99h 59min / ∞
8. Display Resolution 0.1°C
9. Lift Travel 200 mm
10. Gas Flow Rate 15 L/min
11. Module Slots 1
12. Power 300 W
13. Dimensions (L*W*H) 260*220*475 mm14. Voltage 220V, 50/60Hz
15. Weight 7.0 kg

4. YKDC-200 Modules
Model Test tube diameter Tubes CapacityMD50 10mm（Depth47mm） 12
MD51 12mm（Depth47mm） 12
MD52 13mm（Depth47mm） 12
MD53 15mm（Depth47mm） 12
MD54 16mm（Depth47mm） 12
MD55 19mm（Depth47mm） 12
MD56 20mm（Depth47mm） 12
